7320-B-XL-TVP-UO FAG Single Row Angular Contact Ball Bearing 100mm x 215mm x 47mm
Help Articles
Also Try
Tab Washers
Lock Nuts
Metric Oil Seals
Dunlop & Budget Ball Bearings
SKF Ball Bearings
Buy Now
Product Specification
Arrangement
Bearing pair is clearance-free in O- and X-arrangement
Brand
FAG
Cage
Polyamide cage
Clearance
Normal radial clearance
Contact angle
40 degree
Inside Dia
100mm
Material
Standard bearing steel
Outer ring
Without flange/groove
Outside Dia
215mm
Row Type
Single
Seal
None, open bearing
Temperature range
-20 to +120 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
47mm
Reference
7320-B-XL-TVP-UO
Additional Reference:
10017624
Quick Order Code
BB-495643
Product Description
7320-B-XL-TVP-UO FAG Single Row Angular Contact Ball Bearing
This premium single row angular contact ball bearing from FAG is engineered for high-speed, precision applications requiring simultaneous radial and axial load capacity. With robust construction and superior performance characteristics, it is ideal for demanding industrial equipment including gearboxes, spindles, and heavy-duty machinery.
Key Specifications:
- Bore Diameter: 100mm
- Outer Diameter: 215mm
- Width: 47mm
- Contact Angle: 40°
- Row Type: Single row
- Arrangement: Clearance-free in O- and X-arrangement configurations
Technical Features:
- Brand: FAG
- Material: Standard bearing steel construction
- Cage: Polyamide cage for optimized load distribution
- Seal Type: Open bearing (no seal)
- Clearance: Normal radial clearance
- Tolerance Class: P0/PN2 (ABEC 1)
- Outer Ring: Without flange or groove
- Operating Temperature Range: -20°C to +120°C
This bearing delivers exceptional performance in precision applications requiring high speed operation with combined loading. It is suitable for use in pairs for enhanced axial load capacity in demanding industrial environments.
