Quick Code: BB-134850
SF1.1/2DEC RHP 1.1/2inch Flanged Bearing (Eccentric Locking Collar Insert)
Also Try
RHP NP & MP Pillow Blocks
RHP SFT 2 Bolt Flanged
RHP Short Base Pillow Block
RHP Take Up Units
RHP 4 Bolt Catridge
Cylindrical Roller Thrust
Square 4 Bolt
Buy Now
Qty:
Product Specification
A
34.9mm
B
56.34mm
Basic Bearing Insert
1040
Bore Size (d)
1.1/2inch
Brand
RHP
G
12mm
Height (Z)
58.9mm
Hole Centre (J)
101.5mm
Length/Width (L)
130.2x130.2mm
Reference
SF1.1/2DEC-RHP
Quick Order Code
BB-134850
Product Description
SF1.1/2DEC RHP 1.1/2inch Flanged Bearing (Eccentric Locking Collar Insert)
SF normal duty 4 bolt flanged bearing unit complete with eccentric locking collar bearing insert. The cast iron housing includes a grease nipple for re-lubrication. The bearing insert has two grub screws for tightening against the shaft once fitted.
The inserts can be removed allowing you to replace with a new insert once required which can be ordered separately.
