LBCR30D-2LS/HV6 Ewellix Closed Sealed Linear Ball Bearing 30x47x68mm
Also Try
LBBR Ball Bushings
LMK Flanged Ball Bushing
LM Ball Bushings
LME Ball Bushing
LMF Flanged Ball Bushing
Buy Now
Product Specification
Angle compensation
Without misalignment compensation
Brand
Ewellix
Inside Dia
30mm
Material
Steel (with anti-corrosion protection), plastic
Outside Dia
47mm
Seal
Sealed on all sides
Series
Standard series
Temperature range
-30 to +80 °C
Version
Closed
Width
68mm
Reference
LBCR30D-2LS/HV6
Additional Reference:
10171922
Quick Order Code
BB-529503
Product Description
The LBCR30D-2LS/HV6 Ewellix Closed Sealed Linear Ball Bearing is a precision-engineered linear ball bearing designed for reliable linear motion in demanding industrial applications. This sealed bearing combines robust construction with versatile mounting capabilities to deliver exceptional performance in contamination-prone environments.
Design & Construction:
- Comprises a cage and raceway segment assembly to guide balls with exceptional precision
- Features dual rubber seals on all sides for comprehensive protection against contamination, moisture, and debris
- Compact yet robust dimensions: 30mm inside diameter, 47mm outside diameter, 68mm width
- Steel construction with anti-corrosion protection and plastic components for optimal durability
- Standard series bearing with closed housing design
Key Performance Features:
- Heavy load capacity thanks to exceptionally long track length and machined raceway osculation
- Enhanced raceway segments positioned for maximum load-carrying capacity
- Compatible with both closed and adjustable housing installations for design flexibility
- Operating clearance is determined by housing bore tolerance when mounted in closed housings
- When mounted in slotted or adjustable housings, can be configured to provide either operating clearance or preload based on application requirements
- Wide operating temperature range: -30 to +80°C
- No misalignment compensation
Installation & Operation:
- Must be positioned axially via grease fitting or fixation pin for proper alignment
- Sealed design on all sides reduces maintenance requirements and extends bearing life in challenging environments
- Ideal for mid-range industrial machinery, automation equipment, printing systems, material handling applications, and other demanding precision applications where smooth linear motion and substantial load capacity are essential
The LBCR30D-2LS/HV6 offers proven reliability and performance of the LBCR ball bushing series in a sealed configuration, making it an excellent choice for industrial and automation applications requiring superior load handling capabilities with enhanced environmental protection.
