LBCR12D-LS Ewellix Closed Linear Ball Bearing 12x22x32mm
Also Try
LBBR Ball Bushings
LMK Flanged Ball Bushing
LM Ball Bushings
LME Ball Bushing
LMF Flanged Ball Bushing
Buy Now
Product Specification
Angle compensation
Without misalignment compensation
Brand
Ewellix
Inside Dia
12mm
Material
Steel, plastic
Outside Dia
22mm
Seal
Contact seal on one side
Series
Standard series
Temperature range
-30 to +80 °C
Version
Closed
Width
32mm
Reference
LBCR12D-LS
Additional Reference:
10171903
Quick Order Code
BB-529486
Product Description
The LBCR12D-LS Ewellix Closed Linear Ball Bearing is a compact, high-performance linear ball bearing engineered for precision applications requiring reliable linear motion and load support. With dimensions of 12mm (inside diameter) x 22mm (outside diameter) x 32mm (width), this bearing delivers dependable performance in space-constrained installations.
Key Features:
- Cage and raceway segment design to precisely guide balls for smooth linear motion
- Dual rubber seals (LS designation) for reliable protection against contaminants
- Exceptionally long track length enabling solid load capacity relative to bearing size
- Machined raceway osculation for optimized load distribution
- Enhanced raceway segments positioned for maximum load carrying capacity
- Contact seal on one side for enhanced protection
- Closed housing design for secure, integrated installations
- Steel and plastic construction for durability and lightweight operation
Specifications:
- Brand: Ewellix
- Inside Diameter: 12mm
- Outside Diameter: 22mm
- Width: 32mm
- Series: Standard series
- Version: Closed
- Material: Steel, plastic
- Angle Compensation: Without misalignment compensation
- Operating Temperature Range: -30 to +80°C
Applications:
This compact linear ball bearing is ideal for use in:
- Compact automation and machinery requiring smooth linear motion
- Light to moderate load applications with space constraints
- Environments where contamination protection is necessary
- Systems requiring long operational life with minimal maintenance
- Industrial equipment operating across wide temperature ranges
Installation Notes:
The LBCR12D-LS must be positioned in the axial direction during installation, typically via the grease fitting or fixation pin. When mounted in closed housings, the bearing tolerance and operating clearance are determined by the housing bore tolerance, ensuring precise performance and reliable operation.
