7414-BCBM SKF Single Row Angular Contact Ball Bearing
7414-BCBM SKF Single Row Angular Contact Ball Bearing
This premium single row angular contact ball bearing from SKF is engineered for high-speed precision applications requiring simultaneous radial and axial load capacity. As a trusted bearing manufacturer, SKF combines precision engineering with robust construction to ensure reliable operation in demanding industrial environments.
Product Specifications:
- Bore Diameter: 70mm
- Outside Diameter: 180mm
- Width: 42mm
- Configuration: Single Row
- Manufacturer: SKF
- Reference Number: 7414-BCBM
Technical Features:
- Contact Angle: 40 degrees for optimal load distribution and axial rigidity
- Clearance: Normal radial clearance
- Cage: Brass cage for superior stability and reduced friction
- Material: Standard bearing steel for extended service life
- Seal Type: Open bearing (no seal)
- Outer Ring: Without flange or groove
- Tolerance Class: P0/PN2 (ABEC 1)
- Operating Temperature Range: -20°C to +150°C
- Arrangement Options: Suitable for low axial clearance bearing pairs in O- and X-arrangements
Design & Performance Benefits:
- 40-degree contact angle provides excellent axial load capacity and rigidity
- Brass cage ensures smooth operation and reduced maintenance requirements
- Designed for high-speed applications with combined radial and axial loading
- Can be paired with matching bearings for duplex or triplex arrangements
- Low axial clearance options available for precision applications requiring minimal play
- Ideal for applications demanding consistent performance and long operational life
Ideal Applications:
This bearing is particularly well-suited for demanding industrial environments including machine tool spindles, gearboxes, electric motors, pumps, compressors, and other high-speed precision equipment where reliable performance under combined loading is essential.
As part of SKF's extensive range of premium angular contact bearings, this model is available for immediate dispatch and backed by SKF's renowned quality standards.
