Quick Code: BB-499856
7405-BCBM SKF Single Row Angular Contact Ball Bearing
7405-BCBM SKF Single Row Angular Contact Ball Bearing
This precision-engineered SKF angular contact ball bearing is designed for applications requiring simultaneous radial and axial load capacity. As a single row design, it offers reliable performance in high-speed, precision-demanding environments. The bearing pair configuration with low axial clearance provides exceptional stability and is ideal for both O- and X-arrangement preloaded mounting configurations.
Key Features:
- 40° contact angle for optimal load distribution and combined axial-radial load handling
- Bearing pair with low axial clearance in O- and X-arrangements for precision preloaded applications
- Brass cage design for lightweight, reliable operation with excellent cage guidance and reduced friction
- Open bearing design (no seals) allowing for flexible mounting, maintenance, and lubrication options
- SKF manufacturing excellence – a globally recognized bearing manufacturer known for superior quality and precision engineering
- Standard bearing steel construction for durability and long service life
- Normal radial clearance with P0/PN2 tolerance class (ABEC 1 standard)
- Extended operating temperature range from -20°C to +150°C for versatile application capability
Specifications:
- Bore Diameter: 25mm
- Outside Diameter: 80mm
- Width: 21mm
- Configuration: Single Row
- Contact Angle: 40°
- Cage Material: Brass
- Seal Type: Open bearing, no seals
- Clearance: Normal radial clearance
- Arrangement: Bearing pair with low axial clearance in O- and X-arrangements
- Operating Temperature Range: -20°C to +150°C
- Material: Standard bearing steel
- Outer Ring: Without flange/groove
- Tolerance Class: P0/PN2 (ABEC 1)
- Brand: SKF
- Reference: 7405-BCBM
Applications:
These precision angular contact bearings are ideal for high-speed machinery, electric motors, gearboxes, spindle drives, and instrumentation equipment. The low axial clearance bearing pair configuration makes this bearing particularly well-suited for preloaded bearing arrangements requiring minimal backlash and maximum precision. Common applications include:
- High-speed spindle drives and machine tool spindles
- Gearbox and transmission systems
- Electric motors and motor spindles
- Precision machinery and industrial equipment
- Pump and compressor applications requiring combined loads
- Applications requiring tight tolerances and minimal axial play
