7226 BM SKF Single Row Angular Contact Ball Bearing 130mm x 230mm x 40mm
Help Articles
Also Try
Tab Washers
Lock Nuts
Metric Oil Seals
Dunlop & Budget Ball Bearings
SKF Ball Bearings
Buy Now
Product Specification
Arrangement
Standard version
Brand
SKF
Cage
Brass cage
Clearance
Normal radial clearance
Contact angle
40 degree
Inside Dia
130mm
Material
Standard bearing steel
Outer ring
Without flange/groove
Outside Dia
230mm
Row Type
Single
Seal
None, open bearing
Temperature range
-20 to +150 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
40mm
Reference
7226BM
Additional Reference:
10017365
Quick Order Code
BB-495562
Product Description
7226 BM SKF Single Row Angular Contact Ball Bearing
This premium single row angular contact ball bearing from SKF is engineered to handle combined radial and axial loads simultaneously, making it ideal for high-speed precision applications. The robust 130mm bore design provides excellent load capacity and reliability for demanding industrial environments.
Key Features:
- Single row configuration for precision radial and axial load handling
- Brass cage construction for optimized performance and durability
- 40-degree contact angle for enhanced load distribution
- Open bearing design without seals, suitable for pre-lubricated applications
- Normal radial clearance for standard operating conditions
- Standard bearing steel construction with P0/PN2 tolerance class (ABEC 1)
- Wide temperature operating range: -20°C to +150°C
- Generous dimensions: 130mm bore x 230mm OD x 40mm width
Specifications:
- Reference: 7226BM
- Brand: SKF
- Inside Diameter: 130mm
- Outside Diameter: 230mm
- Width: 40mm
- Row Type: Single
- Cage Material: Brass
- Contact Angle: 40 degrees
- Seal Type: Open bearing (None)
- Clearance: Normal radial clearance
- Tolerance Class: P0/PN2 (ABEC 1)
- Operating Temperature Range: -20°C to +150°C
Applications:
This SKF angular contact bearing is ideal for heavy-duty industrial machinery, gearboxes, motor spindles, compressors, and other equipment requiring reliable performance under combined radial and axial loads. The open design makes it particularly suitable for applications where external lubrication systems are employed.
