7217-BEP SKF Single Row Angular Contact Ball Bearing
Help Articles
Also Try
Tab Washers
Lock Nuts
Metric Oil Seals
Dunlop & Budget Ball Bearings
SKF Ball Bearings
Briggs & Stratton (Murray)
Trousers
Buy Now
Product Specification
Arrangement
Standard version
Brand
SKF
Cage
Polyamide cage
Clearance
Normal radial clearance
Contact angle
40 degree
Inside Dia
85mm
Material
Standard bearing steel
Outer ring
Without flange/groove
Outside Dia
150mm
Row Type
Single
Seal
None, open bearing
Temperature range
-20 to +120 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
28mm
Reference
7217-BEP
Additional Reference:
10017294
Quick Order Code
BB-495538
Product Description
7217-BEP SKF Single Row Angular Contact Ball Bearing
The 7217-BEP is a premium single row angular contact ball bearing from SKF, engineered for applications requiring simultaneous radial and axial load capacity at high speeds. This precision bearing is ideal for demanding industrial applications including gearboxes, electric motors, spindles, and heavy-duty machinery.
Key Specifications:
- Bore diameter: 85mm
- Outer diameter: 150mm
- Width: 28mm
- Contact angle: 40°
- Row type: Single row
- Seal type: Open bearing (no seal)
Technical Features:
- Brand: SKF
- Material: Standard bearing steel
- Cage: Polyamide cage for lightweight durability
- Clearance: Normal radial clearance
- Tolerance class: P0/PN2 (ABEC 1)
- Arrangement: Standard version
- Outer ring: Without flange or groove
- Operating temperature range: -20°C to +120°C
Applications:
The 7217-BEP is suitable for high-speed precision applications in automotive transmissions, industrial gearboxes, electric motors, machine tool spindles, and similar equipment where reliability and performance under combined loads are essential.
