7208-B-MP-UO FAG Single Row Angular Contact Ball Bearing 40mm x 80mm x 18mm
7208-B-MP-UO FAG Single Row Angular Contact Ball Bearing
This high-performance single row angular contact ball bearing from FAG is engineered to deliver reliable precision and durability in demanding applications requiring simultaneous radial and axial load capacity. The 7208-B-MP-UO combines robust construction with optimized design, making it an excellent choice for high-speed rotating machinery and heavy-duty industrial equipment.
Specifications:
- Reference Number: 7208-B-MP-UO
- Manufacturer: FAG
- Bore Diameter: 40mm
- Outer Diameter: 80mm
- Width: 18mm
- Row Type: Single Row
- Contact Angle: 40 degrees
- Material: Standard bearing steel
- Cage Type: Brass cage
- Clearance: Normal radial clearance (Tolerance class P0/PN2 / ABEC 1)
- Seal Type: Open bearing (no seals)
- Outer Ring: Without flange/groove
- Operating Temperature Range: -20°C to +150°C
Key Features:
- 40-degree contact angle optimized for combined radial and axial load distribution
- Brass cage construction for smooth, reliable operation and reduced friction
- Clearance-free in O- and X-arrangement configurations for precision bearing pairs
- Open bearing design ideal for applications where minimal drag is required
- Extended temperature range (-20°C to +150°C) for versatile industrial use
- Precision tolerance class P0/PN2 / ABEC 1 for consistent performance
- Compact 18mm width for space-constrained applications
Applications:
The 7208-B-MP-UO is ideal for use in gearboxes, electric motors, machine tool spindles, automotive transmissions, industrial pumps, and other heavy-duty rotating equipment where combined radial and axial loads are present. Its precision design and clearance-free pairing capability make it particularly suitable for applications demanding superior accuracy, long service life, and reliable performance in demanding environments. The brass cage and extended temperature range ensure excellent performance across diverse industrial applications.
Reference Number: 7208-B-MP-UO FAG
