7204-BEP SKF Single Row Angular Contact Ball Bearing
Help Articles
Also Try
Tab Washers
Lock Nuts
Metric Oil Seals
Dunlop & Budget Ball Bearings
SKF Ball Bearings
Buy Now
Product Specification
Arrangement
Standard version
Brand
SKF
Cage
Polyamide cage
Clearance
Normal radial clearance
Contact angle
40 degree
Inside Dia
20mm
Material
Standard bearing steel
Outer ring
Without flange/groove
Outside Dia
47mm
Row Type
Single
Seal
None, open bearing
Temperature range
-20 to +120 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
14mm
Reference
7204-BEP
Additional Reference:
10017124
Quick Order Code
BB-495491
Product Description
The 7204-BEP SKF Single Row Angular Contact Ball Bearing is a premium precision bearing designed for applications requiring simultaneous radial and axial load capacity at moderate to high speeds. This versatile bearing from SKF, a leading global manufacturer, combines reliability with excellent performance characteristics.
Specifications:
- Bore Diameter: 20mm
- Outer Diameter: 47mm
- Width: 14mm
- Row Type: Single row
- Contact Angle: 40°
- Radial Clearance: Normal
- Cage Material: Polyamide
- Bearing Steel: Standard bearing steel
- Seal Type: Open bearing (no seal)
- Outer Ring: Without flange or groove
- Tolerance Class: P0/PN2 (ABEC 1)
- Operating Temperature Range: -20°C to +120°C
- Reference: 7204-BEP
Key Features:
- Single row angular contact design for combined radial and axial loading
- 40° contact angle provides excellent axial load capacity
- High-speed capable with polyamide cage for smooth operation
- Open bearing design suitable for applications where sealing is not required
- Standard clearance configuration ideal for general industrial applications
- Precision tolerance class P0/PN2 ensures consistent performance
Typical Applications:
This bearing is ideal for use in:
- Machine tool spindles
- Precision gearboxes
- Electric motors
- Automotive applications
- Industrial equipment requiring moderate to high-speed operation
- General mechanical engineering applications
The 7204-BEP is stocked for immediate dispatch and offers excellent value for precision applications where SKF quality and reliability are essential.
