3313-BD-XL-2HRS-TVH-C3 FAG Angular Contact Ball Bearing 65mm x 140mm x 58.7mm
3313-BD-XL-2HRS-TVH-C3 FAG Angular Contact Ball Bearing
This premium double row angular contact ball bearing from FAG is engineered to handle combined radial and axial loads in both directions, making it ideal for precision applications requiring reliable performance in demanding industrial environments. The dual lip seals on both sides provide excellent protection against contaminants while maintaining optimal lubrication retention, ensuring consistent operation across a wide temperature range.
Product Specifications:
- Bore Diameter: 65mm
- Outer Diameter: 140mm
- Width: 58.7mm
- Configuration: Double Row
- Contact Angle: 30°
- Cage Material: Polyamide
- Clearance: Slightly increased radial clearance (C3)
- Seal Type: Lip seal on both sides (2HRS)
- Outer Ring: Without flange/groove
- Material: Standard bearing steel
- Tolerance Class: P6 / ABEC 3 (high precision)
- Operating Temperature Range: -20°C to +120°C
- Manufacturer: FAG
- Reference Number: 3313-BD-XL-2HRS-TVH-C3
Design & Performance Features:
- Double row configuration for superior bidirectional axial and radial load capacity with enhanced stiffness
- Dual lip seals (2HRS) on both sides for enhanced protection and contamination resistance in harsh environments
- Polyamide cage design for lightweight operation and excellent performance at moderate to high speeds
- Slightly increased radial clearance (C3) accommodates thermal expansion and provides flexibility in mounting applications
- 30-degree contact angle for optimal load distribution and balanced radial-axial performance
- High precision tolerance class P6 / ABEC 3 for demanding industrial applications
- Standard bearing steel construction ensuring durability and reliability
- Compact yet robust design ideal for space-constrained applications requiring substantial load capacity
- Non-flange outer ring design for versatile mounting options
Typical Applications:
- Gearboxes and transmission systems
- Electric motors and generators
- Industrial pumps and compressors
- Machine tool spindles and precision machinery
- Automotive and aerospace components
- Heavy-duty industrial equipment
- Conveyor systems and material handling equipment
- HVAC systems and cooling equipment
- Medium to large-scale machinery with combined loading conditions
As a FAG product featuring sealed design, precision engineering, and increased clearance capability, this bearing represents premium quality and reliability for applications requiring protection from dust and moisture while maintaining consistent performance under combined loading conditions in varying thermal environments.
