3207-B-2RS Zen Double Row Angular Contact Ball Bearing 35mm x 72mm x 27mm
3207-B-2RS Zen Double Row Angular Contact Ball Bearing
This premium Zen double row angular contact ball bearing is engineered to handle simultaneous radial and axial loads in both directions, making it ideal for high-speed precision applications requiring enhanced load capacity and rigidity. The double row configuration provides superior performance compared to single row bearings, delivering exceptional durability and reliability for demanding industrial environments.
Key Features:
- Double row configuration for increased load carrying capacity and enhanced rigidity
- 40° contact angle on both rows for optimal load distribution and combined load capacity
- Lip seals on both sides providing effective protection against contamination and moisture ingress
- Polyamide cage construction for smooth operation and reduced friction
- Standard bearing steel construction with P0/PN2 (ABEC 1) tolerance class for precision performance
- Non-separable design for secure and stable installation
- Normal radial clearance suitable for standard mounting applications
Specifications:
- Reference Number: 3207-B-2RS
- Manufacturer: Zen
- Bore Diameter: 35mm
- Outer Diameter: 72mm
- Width: 27mm
- Type: Double Row Angular Contact
- Contact Angle: 40°
- Cage Type: Polyamide
- Seal Type: Lip seal on both sides
- Material: Standard bearing steel
- Tolerance Class: P0/PN2 (ABEC 1)
- Operating Temperature Range: -20°C to +120°C
- Arrangement: Standard version
Typical Applications:
This versatile double row angular contact bearing is ideal for applications requiring bidirectional load support and enhanced axial rigidity. Common uses include gearboxes, electric motors, machine tool spindles, automotive transmissions, industrial pumps, and precision machinery. The sealed design with lip seals on both sides makes it particularly well-suited for applications where protection from dust, moisture, and contaminants is essential. The 35mm bore size makes it ideal for medium-duty equipment operating at high speeds with combined loading conditions.
Zen double row angular contact bearings are renowned for their reliability and performance, making them an excellent choice for industrial applications demanding durability, precision, and long service life.
