HDR15 VSS THK Carriage
Also Try
Bosch Rexroth Carriages
Hiwin Carriages
INA Carriages
NSK Carriages
Schneeberger Carriages
Buy Now
Product Specification
Ball chain
Without ball chain
Ball-/Roller rows
Four Row
Brand
THK
Design
Block carriage
Lubrication & Maintenance
Can be relubricated (via the lubrication nipple)
Material
Steel, Plastic
Preload
Normal preload
Seal
End Seals, Sealing Strips and Inner Seals
Series
15 series
Temperature range
-20 to +80 °C
Tolerance class
Normal Class
Type of rolling elements
Balls
Version
Low design
Reference
HDR15VSS
Additional Reference:
10192115
Quick Order Code
BB-531495
Product Description
The HDR15 VSS THK Carriage is a precision linear motion component engineered to deliver smooth, accurate movement in demanding industrial applications. Part of THK's extensive carriage lineup, this block carriage combines advanced engineering with robust construction to meet diverse operational requirements while maintaining a low-profile design for space-constrained installations.
Key Features
- Design: Block carriage configuration for direct mounting and versatile installation options
- Version: Low design for applications requiring compact vertical dimensions and space optimization
- Rolling Elements: Four-row ball arrangement without ball chain for efficient load distribution and smooth operation
- Material Construction: Durable steel and plastic composition for optimal durability and reliable performance
- Sealing System: Comprehensive protection featuring end seals, sealing strips, and inner seals to protect against contamination and extend service life in industrial environments
- Preload: Normal preload setting for balanced load capacity and consistent smooth movement
- Tolerance Class: Normal precision class suitable for standard industrial applications
- Lubrication: Relubrication capability via lubrication nipple for easy maintenance and extended component life
- Operating Temperature Range: -20 to +80°C for reliable performance in varied environmental conditions
- Series: 15 series - part of THK's proven carriage lineup for compact load applications
Ideal Applications
The HDR15 VSS is well-suited for machinery requiring precision linear guidance with space constraints, including:
- Automated manufacturing equipment with height-restricted design requirements
- CNC machining systems and precision positioning equipment
- Industrial automation platforms requiring low-profile components
- Conveyor and material handling systems with limited vertical space
- Packaging and assembly machinery
- Compact automation frameworks and positioning systems
Brand: THK | Reference: HDR15VSS
