HDR15 LCSS THK Carriage
Also Try
Bosch Rexroth Carriages
Hiwin Carriages
INA Carriages
NSK Carriages
Schneeberger Carriages
Buy Now
Product Specification
Ball chain
Without ball chain
Ball-/Roller rows
Four Row
Brand
THK
Design
Flange carriage
Lubrication & Maintenance
Can be relubricated (via the lubrication nipple)
Material
Steel, Plastic
Preload
Normal preload
Seal
End Seals, Sealing Strips and Inner Seals
Series
15 series
Temperature range
-20 to +80 °C
Tolerance class
Normal Class
Type of rolling elements
Balls
Version
Wide and long design
Reference
HDR15LCSS
Additional Reference:
10192120
Quick Order Code
BB-531496
Product Description
The HDR15 LCSS THK Carriage is a precision linear motion component engineered to deliver reliable performance in demanding industrial applications. This wide and long design flange carriage provides smooth, accurate movement when paired with THK linear guide rails, making it an ideal choice for automation equipment, manufacturing machinery, CNC systems, and precision positioning applications requiring extended travel and robust load handling.
Key Features:
- Wide and Long Design: Extended form factor optimized for applications requiring longer travel distances and greater load distribution across the carriage profile
- Flange Design: Flange carriage configuration enables versatile mounting options and flexible installation configurations
- Series 15: Part of THK's comprehensive range of precision carriages with proven performance across diverse industrial sectors
- Four-Row Ball Elements: Four-row ball arrangement ensures superior load distribution, stability, and consistent, precise linear motion
- Comprehensive Sealing System: End seals, sealing strips, and inner seals provide robust contamination protection suitable for challenging industrial environments
- Relubrication Capability: Can be relubricated via lubrication nipple for convenient maintenance and extended service life in long-running applications
- Durable Construction: Steel and plastic materials combine strength with wear resistance for long-term reliability and corrosion resistance
- Normal Preload: Optimized for balanced performance, minimal play, and smooth operation across a wide range of motion requirements
- Normal Tolerance Class: Meets standard precision requirements for most industrial applications
- Wide Operating Temperature: Functions reliably across -20 to +80°C temperature range for diverse environmental conditions
- Without Ball Chain: Streamlined design without integrated ball chain for specific application requirements
Ideal Applications:
The HDR15 LCSS carriage is particularly well-suited for:
- Large-format automation systems requiring extended travel distances
- Heavy-duty manufacturing and industrial machinery
- CNC machines and precision machining centers
- Automation equipment with demanding load requirements
- Material handling and positioning systems
- Industrial assembly and production line applications
- Systems requiring extended operational life through relubrication
The HDR15 LCSS carriage combines precision engineering with practical durability, delivering consistent, reliable performance across a wide range of industrial positioning, automation, and motion control tasks.
Brand: THK | Reference: HDR15LCSS
