MFC30 RHP 30mm Cartridge Bearing
Also Try
RHP NP & MP Pillow Blocks
RHP SF 4 Bolt Flanged
RHP SFT 2 Bolt Flanged
RHP Short Base Pillow Block
RHP Take Up Units
Buy Now
Qty:
Product Specification
Bolt Hole Dia (N)
10mm
Bolt Hole PCD (P)
104.78mm
Bore Size (d)
30mm
Brand
RHP
Outside Dia (D)
127.00mm
Reference
MFC30-RHP
Quick Order Code
BB-7942
Product Description
The MFC30 RHP 30mm Cartridge Bearing is a robust, heavy-duty housed bearing unit designed for demanding industrial applications requiring reliable shaft support and easy maintenance.
Key Features:
- Heavy-duty cast iron housing with integrated bearing insert
- Grease nipple for convenient re-lubrication
- Two grub screws for secure shaft mounting
- Removable insert for easy replacement
- Constructed from MFC2CAS Housing and 1035-30G Insert
Technical Specifications:
- Bore Size: 30mm
- Outside Diameter: 127.00mm
- Bolt Hole Diameter: 10mm
- Bolt Hole PCD: 104.78mm
- Brand: RHP
- Equivalent Part Number: UCFCX06
Typical Applications:
- Industrial machinery
- Conveyor systems
- Material handling equipment
- Agricultural machinery
- Construction equipment
- Mining and processing machinery
The removable insert design allows for cost-effective maintenance, enabling users to replace only the insert when worn, rather than the entire bearing unit. This makes the MFC30 an economical and practical solution for continuous industrial operations.
