Quick Code: BB-535719
LMEK16 UU Samick Closed Sealed Linear Ball Bearing 16x26x36mm
Also Try
LBBR Ball Bushings
LMK Flanged Ball Bushing
LM Ball Bushings
LME Ball Bushing
LMF Flanged Ball Bushing
Buy Now
Product Specification
Angle compensation
Without misalignment compensation
Brand
Samick
Form
Square
Inside Dia
16mm
Material
Standard bearing steel
Outside Dia
26mm
Seal
Sealed on all sides
Temperature range
-20 to +80 °C
Version
Closed
Width
36mm
Reference
LMEK16UU
Additional Reference:
10248363
Quick Order Code
BB-535719
Product Description
LMEK16UU Samick Closed Sealed Linear Ball Bearing
The LMEK16UU is a precision-engineered flanged linear ball bushing from Samick, designed to deliver smooth and reliable linear motion in light-duty industrial applications. Featuring a compact 16mm bore with a sealed design, this bushing combines durability with excellent performance across a wide temperature range.
Specifications:
- Inside Diameter: 16mm
- Outside Diameter: 26mm
- Width: 36mm
- Brand: Samick
- Form: Square flange
- Seal: Closed sealed on all sides (UU Configuration)
- Material: Standard bearing steel
- Temperature Range: -20°C to +80°C
- Misalignment Compensation: Without
Key Features:
- Square flange design for secure, stable mounting
- Fully sealed construction protects internal ball bearings from contamination, dust, and debris
- Precision-machined for smooth, consistent linear motion
- Compact design ideal for space-constrained applications
- Wide operating temperature range for versatile industrial use
- Premium Samick quality and reliability
Applications:
The LMEK16UU is ideal for light-duty linear motion applications, including:
- Food processing machinery
- Conveyor systems
- Material handling equipment
- Textile machines
- Baggage handling systems
- Medical processing equipment
- Automated assembly equipment
The sealed construction ensures extended bearing life and reduced maintenance, making the LMEK16UU an excellent choice for demanding industrial environments requiring dependable linear motion performance.
