SR168-2Z ZEN Stainless Shielded Deep Groove Ball Bearing 6.35mm x 9.526mm x 3.175mm
Help Articles
Also Try
Metric Oil Seals
Imperial Oil Seals
Dunlop & Budget Ball Bearings
SKF Ball Bearings
Buy Now
Qty:
Product Specification
Ball rows
Single row bearing
Bore
Cylindrical bore
Brand
ZEN
Cage
Sheet steel cage
Clearance
Normal radial clearance
Current insulation
No current insulation
Inside Dia
6.35mm = 1/4inch
Material
Stainless steel
Material of rolling elements
Stainless steel
Outer ring
Without flange/groove
Outside Dia
9.525mm = 3/8inch
Sealing
Shielded
Temperature range
-30 to +150 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
3.175mm = 1/8inch
Reference
SR168-2Z
Additional Reference:
10128380
Quick Order Code
BB-517686
Product Description
The SR168-2Z ZEN Stainless Shielded Deep Groove Ball Bearing is a precision-engineered component designed for compact and demanding mechanical applications. This imperial-sized bearing offers exceptional performance with its stainless steel construction and compact 1/4 inch bore.
Key Features:
- Single row deep groove ball bearing design
- Stainless steel material for superior corrosion resistance
- Shielded design for enhanced protection against contaminants
- Imperial inch-based sizing (1/4 inch inside diameter)
- Sheet steel cage for durability
Technical Specifications:
- Inside Diameter: 6.35mm (1/4 inch)
- Outside Diameter: 9.525mm (3/8 inch)
- Width: 3.175mm (1/8 inch)
- Material: Stainless steel (both bearing and rolling elements)
- Cage Type: Sheet steel
- Sealing: Shielded (2Z)
- Clearance: Normal radial clearance
- Tolerance Class: P0/PN2 / ABEC 1
- Temperature Range: -30°C to +150°C
Ideal Applications:
- Precision medical equipment
- Food processing machinery
- Marine and coastal applications
- Laboratory and scientific instruments
- Small mechanical devices requiring corrosion resistance
- Miniature automotive components
- Electronics and telecommunications equipment
The stainless steel construction and shielded design make this bearing particularly suitable for environments requiring corrosion resistance and protection from dust and moisture. Its compact size and robust materials ensure reliable performance across a wide range of temperature conditions.
Brand: ZEN
