Fluro Rod Ends - Series G
Fluro Rod Ends - Series G - Male
Quick Code: BB-157503
GAL18 Fluro 18mm Bore M18x1.5 Male L/H Steel, Bronze Lined Rod End
Also Try
Fluro Rod Ends - Series G - Female
Buy Now
Qty:
Product Specification
B
23mm
Bore Size (D)
18mm
F
72mm
G
M18x1.5
GL
44mm
Housing Dia (A)
46mm
M
16.5mm
Materials
Steel, Bronze Lined
O
21.8mm
Overall Length (L)
95mm
Right Hand or Left Hand
Left Hand
Reference
GAL18
Brand
Fluro
Quick Order Code
BB-157503
Product Description
GAL18 Fluro 18mm Bore M18x1.5 Male L/H Steel, Bronze Lined Rod End
Rod end with male thread made from free-cutting or heat-treated steel, zinc plated and fitted with a grease nipple. Especially suited for axial loads.
Materials:
Housing: up to size 12 turned from free-cutting steel to 9SMnPb28k, 12L13
from size 14 forged from heat-treated steel to C22, M1023
Insert: Special brass to CuZn38AI1
Ball: Bearing steel to 100Cr6, Aisi 52100, hardened, ground, polished
