FPL-M10SS 10mm Left Hand Rod End Bearing - Stainless Steel
Also Try
Female Rod Ends (Bronze Race)
Female Rod Ends (Stainless Steel, PTFE Liner)
Fluro Rod Ends - Series G - Female
Female Rod Ends (PTFE Liner)
Fluro Rod Ends - Series E - Female
Buy Now
Product Specification
AF
17.00mm
Ball Width (W)
14mm
Bore Size
10mm
Housing Depth (H)
10.50mm
Housing Dia (D)
26mm
Length of Thread (L2)
21mm
Shaft Centre Height (L1)
43mm
Thread
M10x1.50
Thread Direction
Left Hand
Brand
DUNLOP
Quick Order Code
BB-88444
Product Description
The FPL-M10SS 10mm Left Hand Rod End Bearing is a high-performance stainless steel female rod end designed for precision industrial and mechanical applications. Part of Dunlop's robust FP-Series, this bearing offers exceptional durability, corrosion resistance, and reliability in challenging environments.
Key Features:
- Manufactured by Dunlop, a trusted industrial components manufacturer
- 3-piece standard design for versatile industrial applications
- Self-lubricating with low friction and excellent wear resistance
- Exceptional moisture resistance
- Wide operating temperature range
- Left-hand thread configuration
- No maintenance required
- ELV & RoHS Compliant
Material Specifications:
- Housing: Stainless Steel (303L/304)
- Race: GR-Nylon, LV-3H
- Ball: Stainless Steel 440C
Technical Specifications:
- Bore Size: 10mm
- Thread: M10x1.50 Left Hand
- Housing Diameter (D): 26mm
- Housing Depth (H): 10.50mm
- Ball Width (W): 14mm
- Shaft Centre Height (L1): 43mm
- Thread Length (L2): 21mm
- AF: 17.00mm
Potential Applications:
- Marine and coastal equipment
- Food processing machinery
- Chemical processing equipment
- Medical and pharmaceutical machinery
- Automotive and transportation systems
- Precision engineering applications
- Corrosion-resistant mechanical systems
Mounting Recommendations:
For optimal performance and extended product life, it is recommended to mount rod ends vertically, with the housing member positioned at the top. This orientation maximizes efficiency and helps maintain the bearing's long-term operational integrity.
