Bearings
Ball Bearings
Dunlop & Budget Ball Bearings
Quick Code: BB-517547
S683-2RS ZEN Stainless Sealed Deep Groove Ball Bearing 3mm x 7mm x 3mm
Help Articles
Also Try
A Belts (13mm x 8mm)
Metric Sizes - Dunlop & Budget
Metric Oil Seals
Miniature Bearings
FAG Ball Bearings
Buy Now
Qty:
Product Specification
Ball rows
Single row bearing
Bore
Cylindrical bore
Brand
ZEN
Cage
Sheet steel cage
Clearance
Normal radial clearance
Current insulation
No current insulation
Inside Dia
3mm
Material
Stainless steel
Material of rolling elements
Stainless steel
Outer ring
Without flange/groove
Outside Dia
7mm
Sealing
Sealed
Temperature range
-20 to +120 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
3mm
Reference
S683-2RS
Additional Reference:
10128119
Quick Order Code
BB-517547
Product Description
The S683-2RS ZEN Stainless Sealed Deep Groove Ball Bearing is a precision miniature bearing designed for high-performance applications requiring compact, durable, and corrosion-resistant components. This ultra-small stainless steel bearing offers exceptional reliability in challenging environments.
Key Features:
- Stainless steel construction for superior corrosion resistance
- Sealed design (2RS) providing excellent protection against contaminants
- Single row deep groove configuration
- Compact dimensions: 3mm x 7mm x 3mm
- Cylindrical bore for versatile mounting
- Sheet steel cage
- Normal radial clearance
Technical Specifications:
| Brand: | ZEN |
| Inside Diameter: | 3mm |
| Outside Diameter: | 7mm |
| Width: | 3mm |
| Material: | Stainless Steel |
| Sealing Type: | Sealed (2RS) |
| Temperature Range: | -20°C to +120°C |
| Tolerance Class: | P0/PN2 / ABEC 1 |
Typical Applications:
- Precision medical devices
- Miniature robotics
- Small electronic equipment
- Micro-mechanics
- Compact scientific instruments
- Dental and surgical tools
- Miniature motors and actuators
The S683-2RS ZEN bearing provides exceptional performance in applications requiring a small, sealed, and corrosion-resistant bearing. Its stainless steel construction and sealed design ensure long-lasting reliability and protection against moisture, dust, and contaminants.
