Quick Code: BB-523271
S61700 ZEN Stainless Open Deep Groove Ball Bearing 10mm x 15mm x 3mm
Help Articles
Also Try
A Belts (13mm x 8mm)
Dunlop Taper Roller Bearings
Metric Oil Seals
Miniature Bearings
FAG Ball Bearings
Buy Now
Qty:
Product Specification
Ball rows
Single row bearing
Bore
Cylindrical bore
Brand
ZEN
Cage
Sheet steel cage
Clearance
Normal radial clearance
Current insulation
No current insulation
Inside Dia
10mm
Material
Stainless steel
Material of rolling elements
Stainless steel
Outer ring
Without flange/groove
Outside Dia
15mm
Sealing
Open
Temperature range
-20 to +120 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
3mm
Reference
S61700
Additional Reference:
10144889
Quick Order Code
BB-523271
Product Description
The S61700 ZEN Stainless Open Deep Groove Ball Bearing is a precision miniature bearing designed for compact and high-performance mechanical applications. With its ultra-small dimensions and stainless steel construction, this bearing offers exceptional durability and reliability in minimal space.
Key Features:
- Extremely compact dimensions: 10mm x 15mm x 3mm
- Single row deep groove ball bearing configuration
- Open design for direct lubrication access
- Stainless steel material for superior corrosion resistance
- Sheet steel cage for enhanced durability
- Cylindrical bore for versatile mounting
- Normal radial clearance
Technical Specifications:
- Inside Diameter: 10mm
- Outside Diameter: 15mm
- Width: 3mm
- Material: Stainless Steel
- Rolling Elements: Stainless Steel
- Sealing: Open
- Temperature Range: -20°C to +120°C
- Tolerance Class: P0/PN2 / ABEC 1
- Cage Material: Sheet steel
- Outer Ring: Without flange/groove
- Current Insulation: None
Typical Applications:
- Precision instrumentation
- Small electrical devices
- Miniature robotics
- Compact sensor mechanisms
- Watchmaking equipment
- Medical device components
- Aerospace and micro-mechanical systems
Benefits:
- Excellent corrosion resistance
- Easy lubrication due to open design
- Reliable performance in various temperature conditions
- Minimal space requirements
- Smooth and consistent rotation
The S61700 ZEN bearing's compact size and stainless steel construction make it an ideal solution for applications requiring high precision, durability, and performance in extremely small spaces.
