Bearings
Ball Bearings
Dunlop & Budget Ball Bearings
Quick Code: BB-516891
F61802-2Z ZEN Shielded Deep Groove Ball Bearing 15mm x 24mm x 5mm
Help Articles
Also Try
A Belts (13mm x 8mm)
Metric Sizes - Dunlop & Budget
Metric Oil Seals
Miniature Bearings
FAG Ball Bearings
Thin Section Ball Bearings
Buy Now
Qty:
Product Specification
Ball rows
Single row bearing
Bore
Cylindrical bore
Brand
ZEN
Cage
Sheet steel cage
Clearance
Normal radial clearance
Current insulation
No current insulation
Inside Dia
15mm
Material
Standard bearing steel
Material of rolling elements
Standard bearing steel
Outer ring
Flange on outer ring
Outside Dia
24mm
Sealing
Shielded
Temperature range
-30 to +150 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
5mm
Reference
F61802-2Z
Additional Reference:
10126730
Quick Order Code
BB-516891
Product Description
The F61802-2Z ZEN Shielded Deep Groove Ball Bearing is a precision-engineered compact bearing designed for applications requiring high performance in small spaces. This miniature ball bearing offers reliable performance with its robust construction and dependable design.
Key Technical Specifications:
- Dimensions: 15mm x 24mm x 5mm
- Single row deep groove design
- Standard bearing steel construction
- Shielded type (2Z sealing)
- Sheet steel cage
- Normal radial clearance
Technical Details:
- Inside Diameter: 15mm
- Outside Diameter: 24mm
- Width: 5mm
- Bore Type: Cylindrical
- Tolerance Class: P0/PN2 / ABEC 1
- Temperature Range: -30°C to +150°C
- Current Insulation: No
- Outer Ring: Flange on outer ring
Typical Application Areas:
- Precision electronics
- Small motors
- Miniature machinery
- Robotics
- Medical devices
- Automotive sensors
- Office equipment
- Compact mechanical systems
Key Advantages:
- Compact and lightweight design
- Shielded configuration for dust and contamination protection
- Standard bearing steel ensures durability
- Suitable for low to medium load applications
- Wide operating temperature range
- Flange on outer ring provides additional mounting stability
A versatile and reliable solution for applications requiring a small, precision ball bearing with excellent performance characteristics and robust construction.
