Bearings
Ball Bearings
Dunlop & Budget Ball Bearings
Quick Code: BB-495944
6240-M ZEN Open Deep Groove Ball Bearing 200mm x 360mm x 58mm
Help Articles
Also Try
A Belts (13mm x 8mm)
Dunlop Taper Roller Bearings
Metric Oil Seals
Miniature Bearings
FAG Ball Bearings
Buy Now
Product Specification
Ball rows
Single row bearing
Bore
Cylindrical bore
Brand
ZEN
Cage
Brass cage
Clearance
Normal radial clearance
Current insulation
No current insulation
Inside Dia
200mm
Material
Standard bearing steel
Material of rolling elements
Standard bearing steel
Outer ring
Without flange/groove
Outside Dia
360mm
Seal Type
None, open bearing
Sealing
Open
Temperature range
-30 to +150 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
58mm
Reference
6240M
Additional Reference:
10147034
Quick Order Code
BB-495944
Product Description
The 6240-M ZEN Open Deep Groove Ball Bearing is a robust and high-performance industrial bearing designed for demanding applications requiring large-scale mechanical support. This substantial single-row bearing offers exceptional reliability and versatility across multiple industrial sectors.
Key Features:
- Massive dimensions: 200mm x 360mm x 58mm
- Single row deep groove configuration
- Open bearing design for optimal lubrication
- Cylindrical bore for flexible mounting
- Brass cage for enhanced durability
Technical Specifications:
- Brand: ZEN
- Internal Diameter: 200mm
- External Diameter: 360mm
- Width: 58mm
- Material: Standard bearing steel
- Cage Material: Brass
- Sealing Type: Open
- Clearance: Normal radial clearance
- Temperature Range: -30°C to +150°C
- Tolerance Class: P0/PN2 / ABEC 1
Typical Applications:
- Heavy industrial machinery
- Large-scale manufacturing equipment
- Construction machinery
- Mining and extraction equipment
- Large rotating systems
The open design ensures excellent lubrication capabilities, while the robust construction provides reliable performance in challenging industrial environments. Ideal for applications requiring high load-bearing capacity and consistent operational reliability.
