Bearings
Cam Followers
CRH Series
Quick Code: BB-681564
CRH10-1VBUU IKO Full complement cam follower with needle rollers
Also Try
CF Series
KR-PP Series
KRV-PP Series
NUKR Series
CF.F Series
Thin Section Ball Bearings
Weld On Hubs
Buy Now
Qty:
Product Specification
Brand
IKO
Inner Diameter
6.35mm
Outer Diameter
15.88mm
Width
12.8mm
Quick Order Code
BB-681564
Product Description
The CRH10-1VBUU IKO is a cam follower with needle rollers. These rolling elements combine high load capacity with a compact design. Cam followers are designed for use with various types of tracks. Thanks to a thick-walled outer ring, they can withstand high radial loads. Instead of an inner ring, they feature a solid, threaded stud, enabling easy mounting. Axial loads due to alignment errors or misalignment can be absorbed in both directions. They are not mounted in a housing bore, but a flat (counter) track provides support.
The CRH10-1VBUU IKO has a full complement design. The absence of a cage allows for a greater number of rolling elements, making this cam follower radially highly loadable. Full complement cam followers are also more shock-resistant than cam followers with a cage. However, the maximum rotational speed is lower than that of caged variants. Common applications of cam followers include conveyor systems, linear guidance systems, and cam mechanisms.
