Quick Code: BB-504109
234419-M-SP FAG Axial Angular Contact Ball Bearing 95mm x 145mm x 60mm
FAG Axial Angular Contact Ball Bearing – Model 234419-M-SP
The 234419-M-SP is a premium axial angular contact ball bearing from FAG, engineered for demanding applications requiring exceptional load capacity, rigidity, and precision. With its 60-degree contact angle, this bearing is specifically designed to support both radial and high axial forces, making it ideal for highly dynamic operations.
Key Specifications:
- Inside Diameter: 95mm
- Outside Diameter: 145mm
- Width: 60mm
- Contact Angle: 60 degrees
- Cage Material: Brass cage for reliable operation and low friction
- Sealing Type: Open design
- Operating Direction: Double direction bearing – capable of handling loads in both directions
- Tolerance Class: SP (high precision)
- Material: Standard bearing steel
- Mounting: Fixed with fixing holes for secure installation
- Operating Temperature Range: -30 degreeC to +150 degreeC
Application Areas:
This bearing is ideal for use in machine tools, pumps, compressors, gearboxes, and other industrial equipment where high precision, load capacity, and bidirectional load handling are critical. Its robust construction and wide temperature range make it suitable for both standard and challenging operating environments.
Product Range: Single bearing unit
