10B1 5/8inch Simplex Platewheel
Quick Code: BB-96211
PW110B/23 5/8inch x 23 Teeth Simplex Platewheel
Also Try
08B1 1/2inch Simplex Platewheel
06B1 3/8inch Simplex Platewheel
12B1 3/4inch Simplex Platewheel
16B1 1inch Simplex Platewheel
American Standard
Buy Now
Product Specification
Bore Size (D)
12mm
Number of Teeth
23
Outside Dia (De)
123.4mm
Pitch Dia (Dp)
116.58mm
Tooth Width (h1)
9.1mm
Reference
5SR23PW
Brand
Medway
Quick Order Code
BB-96211
Product Description
The PW110B/23 5/8inch x 23 Teeth Simplex Platewheel is a precision-engineered sprocket designed for single-strand chain drive applications. As a platewheel sprocket, it features no boss diameter, making it an ideal choice for space-constrained installations and versatile industrial applications.
Key Specifications:
- Bore Size: 12mm
- Number of Teeth: 23
- Outside Diameter: 123.4mm
- Pitch Diameter: 116.58mm
- Tooth Width: 9.1mm
- Reference Code: 5SR23PW
- Brand: Medway
Applications:
Simplex platewheels are commonly used in a wide range of industrial and commercial applications including:
- Conveyor systems
- Light to medium-duty power transmission
- Machinery and equipment drives
- Agricultural equipment
- General mechanical drive systems
The compact design and lack of boss diameter make this platewheel an excellent solution for applications requiring efficient, reliable chain drive performance without unnecessary bulk.
