Quick Code: BB-368915
FG4585 EESW Nadella Track Roller Bearing
Also Try
INA Track Roller Bearings LR5
INA Track Roller Bearings LFR5
INA Track Rollers Bearings LR6
INA Track Roller Bearings LR2
ZEN Track Roller Bearings
Buy Now
Qty:
Product Specification
Ball rows
Single row bearing
Cage
None, full complement needle bearing
Eccentric ring
Without eccentric ring
Inner dimension
45mm
Material
Standard bearing steel
Outer dimension
85mm
Outer ring
Spherical outside surface
Seal
Lip seal on both sides
Temperature range
-20 to +120 Deg C
Width
32mm
Reference
FG4585EESW
Additional Reference:
10173746
Brand
Nadella
Quick Order Code
BB-368915
Product Description
The FG4585 EESW Nadella Track Roller Bearing is a precision-engineered single row needle bearing designed for reliable linear motion guidance in demanding industrial applications. Manufactured by the renowned French bearing specialist Nadella, this robust track roller offers exceptional performance with its advanced design and durable construction.
Key Technical Specifications:
- Dimensional Characteristics:
- Inner Diameter: 45mm
- Outer Diameter: 85mm
- Width: 32mm
- Bearing Configuration:
- Single row design
- Full complement needle bearing (without separate cage)
- Spherical outer ring surface
- Without eccentric ring
- Material and Performance:
- Constructed from standard bearing steel
- Operating temperature range: -20°C to +120°C
- Sealed with lip seals on both sides for enhanced protection
Typical Applications:
- Precision machinery linear motion systems
- Material handling equipment
- Automotive manufacturing machinery
- Industrial automation equipment
- Conveyor and transport systems
- Robotics and automation
- Agricultural and construction machinery
The FG4585 EESW features a full complement needle design that provides maximum load-bearing capacity with minimal friction. Its lip seals on both sides offer superior protection against contaminants, making it ideal for challenging industrial environments that require smooth and precise linear movement.
