Transmissions V & Wedge Belts V Belts Z Belts (10mm x 6mm)
Quick Code: BB-95

Z77 Dunlop V Belt

Name: Z77 Dunlop V Belt
Brand: Dunlop
SKU: Z77
Price: 5.36 GBP
Availability: InStock

Help Articles

MEASURE A BELT
Fan Belt Calculator

Also Try

A Belts (13mm x 8mm)

SPZ Belts (9.7mm x 8mm)

SPZ Section Cast Iron - Taper Lock

Taper Bushes

AX Cogged Belts (13mm x 8mm)

Buy Now

Qty:

Product Specification

Brand

Dunlop

External Length (Approx)

1993mm

Internal Length (Approx)

1956mm

Pitch Length (Approx)

1978mm

Reference

Z77

Quick Order Code

BB-95

Product Description

Z77 V Belt by Dunlop

The classical wrapped Dunlop V-belt is a temperature and oil resistant universal drive belt that has antistatic properties with good power transmission capabilities. It is suitable for both industrial machinery and agricultural equipment.

Construction and Features

The tensile member consists of a specially treated high strength polyester cord to transmit tensile forces and withstand shock loads.

The fabric jacket provides grip and protection against external agents and resistance to abrasion.

The belt compound converts tensile forces on the sidewalls into longitudinal forces in the tensile member.

Standards

Conform to 1S04184, D1N2215 and BS3790, they meet 1S01813 for static conductivity and have an operating temperature range of -30 degree C - +60 degree C.

Dimension

10mm top width x 6mm deep

V Pulleys To Suit
