Transmissions V & Wedge Belts Wedge Belts SPB Belts (16.3mm x 13mm)
Quick Code: BB-118193

SPB4560 Dunlop Wedge Belt

Name: SPB4560 Dunlop Wedge Belt
Brand: Dunlop
SKU: SPB4560
Price: 35.66 GBP
Availability: InStock

Help Articles

MEASURE A BELT
Fan Belt Calculator

Also Try

SPA Belts (12.7mm x 10mm)

SPZ Belts (9.7mm x 8mm)

Taper Bushes

SPB Section Cast Iron - Taper Lock

SKF Ball Bearings

Buy Now

Qty:

Product Specification

Brand

Dunlop

External Length (Approx)

4582mm

Internal Length (Approx)

4504mm

Pitch Length (Approx)

4560mm

Top Width x Depth (Approx)

16.3mm x 13mm

Reference

SPB4560

Quick Order Code

BB-118193

Product Description

SPB4560 Wedge Belt by Dunlop

The Dunlop wrapped wedge belt is a temperature and oil resistant universal drive belt with antistatic properties that has a deeper cross section than conventional v-belts, this increase in height ensures excellent grip and greater power ratings. They have a wide range of applications in both industrial machinery and agricultural equipment that may require high belt speeds.

Construction and Features

The tensile member consists of a specially treated higher strength polyester cord to transmit tensile forces and withstand shock loads.

The fabric jacket provides grip and protection against external agents and resistance to abrasion.

The belt compound converts tensile forces on the sidewalls into longitudinal forces in the tensile member.

Standards
Dunlop wrapped wedge belts conform to 1S04184, D1N7753 and BS37901 they meet 1S01813 for static conductivity and have an operating temperature range of -30�C - +60�C.

Dimensions

16.3mm top width x 13mm deep

SPB section wedge belt

SPB Pulleys To Suit
