SPA1232 Dunlop Wedge Belt

Name: SPA1232 Dunlop Wedge Belt
Brand: Dunlop
SKU: SPA1232
Price: 12.07 GBP
Availability: InStock

Help Articles

MEASURE A BELT
Fan Belt Calculator

Also Try

A Belts (13mm x 8mm)

SPZ Belts (9.7mm x 8mm)

Taper Bushes

SPA Section Cast Iron - Taper Lock

A Section Mower Belts

B Belts (17mm x 11mm)

Buy Now

Qty:

Product Specification

Brand

Dunlop

External Length (Approx)

1250mm

Internal Length (Approx)

1187mm

Pitch Length (Approx)

1232mm

Top Width x Depth (Approx)

12.7mm x 10mm

Reference

SPA1232

Quick Order Code

BB-116925

Product Description

SPA1232 Wedge Belt by Dunlop

The Dunlop wrapped wedge belt is a temperature and oil resistant universal drive belt with antistatic properties that has a deeper cross section than conventional v-belts, this increase in height ensures excellent grip and greater power ratings. They have a wide range of applications in both industrial machinery and agricultural equipment that may require high belt speeds.

Construction and Features

The tensile member consists of a specially treated higher strength polyester cord to transmit tensile forces and withstand shock loads.

The fabric jacket provides grip and protection against external agents and resistance to abrasion.

The belt compound converts tensile forces on the sidewalls into longitudinal forces in the tensile member.

Standards
Dunlop wrapped wedge belts conform to 1S04184, D1N7753 and BS37901 they meet 1S01813 for static conductivity and have an operating temperature range of -30 deg C - +60 deg C.

Dimensions

12.7mm top width x 10mm deep

SPA section wedge belt
