Bearings
Ball Bearings
SKF Ball Bearings
Quick Code: BB-2024
6209-2Z SKF Shielded Ball Bearing 45mm x 85mm x 19mm
Help Articles
Also Try
N NJ NUP Type Cylindrical Roller
HK Series Drawn Cup Needle Bearings
Metric Oil Seals
Miniature Bearings
FAG Ball Bearings
Budget Taper Roller Bearings
Buy Now
Qty:
Product Specification
Brand
SKF
Clearance
Standard
Inside Dia
45mm
Outside Dia
85mm
RPM Grease
11400
RPM Oil
8400
Sealing
Shielded
Width
19mm
Reference
6209-2Z
Quick Order Code
BB-2024
Product Description
The 6209-2Z SKF Shielded Ball Bearing is a high-performance precision bearing designed for demanding industrial and mechanical applications. Manufactured by SKF, the world's leading bearing manufacturer, this deep groove ball bearing offers exceptional reliability and performance.
Key Features:
- Single row deep groove ball race design
- Metal shields on both sides for superior protection
- Pre-charged with high-quality lubricating grease
- Standard internal clearance
- Dimensions: 45mm internal diameter, 85mm external diameter, 19mm width
Performance Specifications:
- Maximum Grease RPM: 11,400
- Maximum Oil RPM: 8,400
- Shielded sealing prevents contamination
Typical Applications:
- Electric motors
- Automotive systems
- Industrial machinery
- Conveyor equipment
- Agricultural machinery
The metal shields protect against dirt, dust, and external contaminants while helping to retain internal lubrication. This design ensures extended bearing life and consistent performance across various operating conditions. With SKF's renowned quality and engineering excellence, the 6209-2Z bearing provides robust and reliable operation in challenging environments.
