6205-2Z C4 SKF Shielded Ball Bearing 25mm x 52mm x 15mm
Help Articles
Also Try
N NJ NUP Type Cylindrical Roller Bearings
HK Series Drawn Cup Needle Bearings
Metric Oil Seals
Miniature Bearings
FAG Ball Bearings
Metric Flanged Oilite Bearings
SKF Take-up Units
Buy Now
Product Specification
Brand
SKF
Clearance
C4
Inside Dia
25mm
Outside Dia
52mm
RPM Grease
19000
RPM Oil
14000
Sealing
Shielded
Width
15mm
Reference
6205-2Z/C4, 6205-ZZ/C4
Quick Order Code
BB-144163
Product Description
The 6205-2Z C4 SKF Shielded Ball Bearing is a high-performance precision component designed for demanding industrial and mechanical applications. As a product from SKF, the worlds largest bearing manufacturer, this deep groove ball bearing offers exceptional reliability, versatility, and performance.
Key Features:
- Manufactured by SKF, renowned for superior quality and innovation
- Single row deep groove ball race design
- Metal shields provide protection against dirt and contamination
- C4 clearance allowing thermal expansion at high speeds and temperatures
- Pre-charged with high-quality lubricating grease
- Non-separable bearing construction
Technical Specifications:
- Inside Diameter: 25mm
- Outside Diameter: 52mm
- Width: 15mm
- Maximum Rotational Speed (Grease): 19,000 RPM
- Maximum Rotational Speed (Oil): 14,000 RPM
Typical Applications:
- Electric motors
- Automotive components
- Pumps and compressors
- Agricultural machinery
- Conveyor systems
- Small precision equipment
The 6205-2Z C4 bearing is particularly suited for applications requiring high-speed performance and robust protection against external contaminants. Its versatile design and C4 internal clearance make it an excellent choice for environments with significant temperature variations and high-speed operations.
