608-Z/C3 SKF Deep Groove Ball Bearing with Shield on One Side Only 8mm x 22mm x 7mm
The 608-Z/C3 SKF Deep Groove Ball Bearing is a high-performance, precision-engineered component designed for a wide range of applications requiring compact and reliable bearing performance. Manufactured by SKF, the world's leading bearing manufacturer, this single row ball bearing offers exceptional quality and versatility.
Key Features:
- Single row deep groove ball bearing design
- Shielded on one side for enhanced protection
- Slightly increased radial clearance (C3 classification)
- Sheet steel cage for durability
- Compact dimensions: 8mm inside diameter, 22mm outside diameter, 7mm width
- Operating temperature range: -20°C to +120°C
- Tolerance class: P0/PN2 / ABEC 1
Technical Specifications:
- Bore Type: Cylindrical
- Material: Standard bearing steel
- Rolling Elements: Standard bearing steel
- Sealing: Shield on one side only
- Current Insulation: No
- Outer Ring: Without flange/groove
Typical Applications:
- Small electric motors
- Precision machinery
- Automotive components
- Office equipment
- Fans and blowers
- Skateboards and rollerblades
- Robotics and automation systems
The one-sided shield provides excellent protection against dust and contaminants while allowing for easier lubrication and maintenance. With its compact design and robust construction, the 608-Z/C3 SKF bearing delivers reliable performance in compact and demanding applications.
As with all SKF products, this ball bearing represents the pinnacle of engineering excellence, offering superior durability, precision, and reliability across various industrial and mechanical settings.
