Quick Code: BB-368918
FG1740 EESW Nadella Track Roller Bearing
Also Try
INA Track Roller Bearings LR5
INA Track Roller Bearings LFR5
INA Track Roller Bearings LR2
INA Track Rollers Bearings LR6
ZEN Track Roller Bearings
Buy Now
Product Specification
Ball rows
Single row bearing
Cage
None, full complement needle bearing
Eccentric ring
Without eccentric ring
Inner dimension
17mm
Material
Standard bearing steel
Outer dimension
40mm
Outer ring
Spherical outside surface
Seal
Lip seal on both sides
Temperature range
-20 to +120 Deg C
Width
21mm
Reference
FG1740EESW
Additional Reference:
10173758
Brand
Nadella
Quick Order Code
BB-368918
Product Description
The FG1740 EESW Nadella Track Roller Bearing is a precision-engineered single row needle bearing designed for smooth and reliable linear motion guidance in industrial applications. This robust track roller offers exceptional performance across a wide range of mechanical systems.
Key Technical Specifications:
- Bearing Type: Single row full complement needle bearing
- Inner Dimension: 17mm
- Outer Dimension: 40mm
- Width: 21mm
- Material: Standard bearing steel
- Cage: Full complement (no separate cage)
- Outer Ring: Spherical outside surface
- Sealing: Lip seal on both sides
- Eccentric Ring: Without eccentric ring
- Operating Temperature Range: -20°C to +120°C
Typical Applications:
- Precision machinery linear motion systems
- Material handling equipment
- Automotive assembly lines
- Industrial automation equipment
- Conveyor and transport mechanisms
- Textile machinery
- Agricultural equipment
The full complement needle design provides maximum load-bearing capacity with minimal friction, making it ideal for applications requiring smooth and precise linear movement. Its dual lip seals offer superior protection against dust, debris, and contaminants while ensuring optimal lubrication retention.
Part of Nadella's premium track roller series, this bearing represents advanced engineering and reliable performance in demanding industrial environments.
