Pneumatics Malleable Iron Pipe Fittings Beaded Malleable Iron Pipe Fittings Black Finish Male Female Short Bend 90 Degree Black, Fig 1A
Quick Code: BB-662120

3inch BSP Male Female Short Bend 90 Degree Black Malleable Iron, Fig 1A (DIN Standard)

Name: 3inch BSP Male Female Short Bend 90 Degree Black Malleable Iron, Fig 1A (DIN Standard)
Brand: Vale
SKU: MI48BMF
Price: 38.92 GBP
Availability: InStock

Also Try

Female Reducing Socket Black, Fig 240

Female Equal Socket Black, Fig 270

Female Union Black, Fig 340

Male Female Equal Elbow 90 Degree Black, Fig 92

Reducing Bush Black, Fig 241

Buy Now

Qty:

Product Specification

Female Thread Size

3inch BSPP

Finish

Black

Male Thread Size

3inch BSPT

Material

Malleable Iron

Type/Standard

Beaded - DIN

Reference

MI48BMF

Equivalent to:

EE-MI1A-12N

Brand

Vale

Quick Order Code

BB-662120

Product Description

A premium-quality malleable iron fitting designed for industrial pneumatic and fluid systems, featuring a BSPT male thread tand BSPP female thread configuration with a short-radius 90-degree bend. This beaded DIN-standard fitting comes with a black finish and is fully interchangeable with George Fischer (GF) Range components.

Key Features

Interchangeable with the George Fischer (GF) Range

Black finish

Manufactured from premium ASTM A-197, EN 1562:1997 and ISO 5922 compliant malleable iron

Built to conform with BS EN 10242, ISO 49:1994 and DIN 2950 dimensional specifications

Features precision-cut threads in accordance with ISO 7/1 standards

Maximum working pressure: 25 bar (360 psi) at temperatures from -30�C to +120�C

Reduced working pressure: 20 bar (290 psi) at temperatures from +120�C to +300�C

What is the difference between black and galvanised?

Do I need banded or beaded?
