LM08 UU Samick Closed Sealed Linear Ball Bearing 8x15x24mm
Also Try
LBBR Ball Bushings
LMK Flanged Ball Bushing
LME Ball Bushing
LMF Flanged Ball Bushing
KH Ball Bushings
Buy Now
Product Specification
Angle compensation
Without misalignment compensation
Brand
Samick
Inside Dia
8mm
Material
Standard bearing steel
Outside Dia
15mm
Seal
Sealed on all sides
Temperature range
-20 to +80 °C
Version
Closed
Width
24mm
Reference
LM08UU
Additional Reference:
10248251
Quick Order Code
BB-535674
Product Description
The LM08UU Samick Closed Sealed Linear Ball Bearing is a compact, high-performance linear bearing engineered for precision linear motion applications. This sealed ball bushing features a robust construction built from standard bearing steel with a closed design, ensuring exceptional durability and reliable operation in diverse industrial environments.
Specifications:
- Inside Diameter: 8mm
- Outside Diameter: 15mm
- Width: 24mm
- Brand: Samick
- Reference: LM08UU
- Material: Standard bearing steel
- Operating Temperature Range: -20°C to +80°C
- Version: Closed
Key Features:
- Standard bearing steel construction for strength and stability
- Sealed on all sides to protect against contaminants and extend service life
- Closed design for enhanced protection and reliability
- Precision ball bearing technology for smooth, consistent linear motion
- Compact form factor ideal for space-constrained applications
- Without misalignment compensation for straightforward, cost-effective operation
- Wide temperature operating range for versatile environmental applications
Ideal Applications:
The LM08UU is well-suited for compact and precision linear motion applications including:
- CNC machinery and automated precision equipment
- Medical device machinery and instrumentation
- Printing and labeling equipment
- Robotics and automation systems
- Optical and imaging systems
- Laboratory and analytical equipment
- Any application requiring smooth, reliable linear motion with smaller shaft diameters
