LBCT30 D-2LS Ewellix Open Sealed Linear Ball Bearing 30x47x68mm
Also Try
LBBR Ball Bushings
LMK Flanged Ball Bushing
LM Ball Bushings
LME Ball Bushing
LMF Flanged Ball Bushing
Buy Now
Product Specification
Angle compensation
Without misalignment compensation
Brand
Ewellix
Inside Dia
30mm
Material
Steel, plastic
Outside Dia
47mm
Seal
Sealed on all sides
Series
Standard series
Temperature range
-30 to +80 °C
Version
Open
Width
68mm
Reference
LBCT30D-2LS
Additional Reference:
10195712
Quick Order Code
BB-532076
Product Description
The LBCT30D-2LS Ewellix Open Sealed Linear Ball Bearing is a precision open design linear ball bearing engineered for applications requiring multiple shaft supports to prevent shaft bending and ensure stable, accurate linear motion. With a 30mm shaft diameter and sealed design, this bushing delivers reliable performance in demanding linear motion systems.
Key Features:
- 30mm inside diameter for standard shaft compatibility
- 47mm outside diameter with 68mm width for optimal load distribution
- Open design with one raceway segment eliminated for lightweight construction without compromising load capacity
- Dual rubber seals (2 x LS) providing enhanced protection against contamination and debris
- Shoulder design in cage on each side of the opening acts as a gap-type seal for improved sealing performance
- Steel and plastic construction for durability and performance
- Operating temperature range: -30°C to +80°C for versatile environmental compatibility
- Ewellix quality engineering for reliable long-term performance
Applications:
Ideal for use in:
- Multi-point shaft support systems
- Continuous linear motion applications
- Systems requiring high shaft rigidity and minimal deflection
- Industrial automation and machinery
- Precision linear motion guidance in clean or sealed environments
- Applications demanding protection against contamination and debris
Important Installation Notes:
- Must be securely fixed to prevent axial and rotational movements
- Recommended for use in series to maximize shaft support and reduce bending
- Proper installation is essential to maintain bearing performance and longevity
Reference: LBCT30D-2LS
