Quick Code: BB-532068
LBCT16 D-2LS Ewellix Open Sealed Linear Ball Bearing 16x26x36mm
The LBCT16 D-2LS Ewellix Open Sealed Linear Ball Bearing is a precision open-design linear bearing engineered for applications requiring multiple shaft supports to prevent shaft bending and ensure accurate linear motion. This compact bearing combines the benefits of open-design construction with comprehensive sealing protection.
Key Features:
- 16mm inside diameter for compact shaft applications
- 26mm outside diameter with 36mm width for optimal load distribution
- 2 x Sealed design (D-2LS) for enhanced protection against contamination on all sides
- Open design with gap-type seal shoulders for reliable performance
- Ewellix quality and engineering expertise
- Steel and plastic construction for durability and precision
- Operating temperature range: -30°C to +80°C for versatile environmental applications
- Standard series bearing with proven performance characteristics
Design & Construction:
As an LBCT series bearing, this bushing features an open raceway design that eliminates one raceway segment while maintaining excellent load-carrying capacity. The distinctive shoulder in the cage on each side of the opening acts as a gap-type seal, providing superior protection compared to other open-design linear bearings. The sealed configuration offers comprehensive protection against dust and contaminants.
Installation Requirements:
- Must be securely fixed to prevent axial movements
- Must be secured to prevent turning movements
- No angular misalignment compensation available—requires precise shaft alignment
Ideal Applications:
Perfect for compact machinery and equipment requiring continuous or multiple shaft supports, such as printing equipment, packaging machines, automation systems, precision positioning mechanisms, and light-duty industrial applications where shaft alignment and load distribution are critical, combined with the need for reliable sealing protection.
Technical Specifications:
- Reference: LBCT16D-2LS
- Brand: Ewellix
- Inside Diameter: 16mm
- Outside Diameter: 26mm
- Width: 36mm
- Material: Steel, plastic
- Seal Type: Sealed on all sides
- Temperature Range: -30°C to +80°C
