Quick Code: BB-470026
200mm Polyurethane Cast Iron Plate Swivel Castor 1000kg Load
Also Try
Industrial Castors
Stainless Steel
Heavy Duty Castors
Light Duty Castors
Castor Wheels Only
16B2 - 1inch Duplex Chain Sprocket
BZMJ Series White Nylon
Buy Now
Qty:
Product Specification
Castor Height
221-274mm
Diameter
200mm
Load Capacity
1000kg
To Suit Bolt Fixing
12mm
Tread
50mm
Reference
JAZXXHK200PTBJ
Quick Order Code
BB-470026
Product Description
Fabricated 75mm lift swivel jacking bracket with fixing plate fitted with a brown polyurethane tyred cast iron centred wheel with ball bearings.
Wheel diameter 200mm
Tread width 50mm
Overall height when open 683mm and 607mm when closed
Plate size 152mm x 106mm
Hole centres 114mm x 64mm
Load capacity 1000kg
