Quick Code: BB-76306
KLNJ3/16-2RS Budget Imperial Sealed Ball Bearing (R3-2RS) 4.76mm x 12.7mm x 5mm
Help Articles
Also Try
Metric Oil Seals
Imperial Oil Seals
Dunlop & Budget Ball Bearings
SKF Ball Bearings
1610 Taper Bushes
T5 Section (5mm Pitch)
10B2 5/8 Duplex Sprockets
Buy Now
Qty:
Product Specification
Brand
Budget
Dynamic Load
1350N
Inside Dia
4.7625mm = 3/16inch
Outside Dia
12.7mm = 1/2inch
RPM Grease
38000
RPM Oil
45000
Sealing
Sealed
Static Load
490N
Width
5mm = 0.196inch
Reference
KLNJ3/16-2RS-NEU
Quick Order Code
BB-76306
Product Description
The KLNJ3/16-2RS Budget Imperial Sealed Ball Bearing is a precision-engineered solution for compact mechanical applications, designed to deliver exceptional performance in a small package.
Key Features:
- Single row deep groove ball bearing design
- Rubber seals provide superior protection against dust and contaminants
- Helps preserve internal lubrication
- Made in imperial inch measurements, ideal for British and American machinery
Technical Specifications:
- Inside Diameter: 4.7625mm (3/16 inch)
- Outside Diameter: 12.7mm (1/2 inch)
- Width: 5mm (0.196 inch)
- Dynamic Load Rating: 1,350N
- Static Load Rating: 490N
- Maximum RPM (Grease Lubricated): 38,000
- Maximum RPM (Oil Lubricated): 45,000
Typical Applications:
- Precision medical equipment
- Small electronic devices
- Hobby and model machinery
- Precision instrumentation
- Compact motor assemblies
- Model aircraft and drone components
The KLNJ3/16-2RS bearing offers exceptional durability and versatility in a compact imperial-sized design. Its sealed construction ensures long-lasting performance by protecting against external contaminants and preserving internal lubrication. Perfect for engineers and mechanics seeking reliable, high-precision bearings for small-scale mechanical applications.
Reference: KLNJ3/16-2RS-NEU
Brand: Budget
