Quick Code: BB-142213
RCJT25 25mm INA 2 Bolt Flanged Bearing
Also Try
INA 4 Bolt Round
INA 4 Bolt Flanged
INA Bearing Inserts
INA Pillow Block Housed
INA Take Up Units
Full Complement Cylindrical Roller
Buy Now
Qty:
Product Specification
Alternative Part Number
RCJT25-XL-N; RCJT25XLN; RCJT25N
Bolt Hole Centre (J)
99mm
Bore Size (d)
25mm
Brand
INA
Height (U)
46mm
Insert
GE25KRRB
Length (H)
124mm
RHP Equivalent
SFT25DEC
Width (L)
70mm
Reference
RCJT25
Quick Order Code
BB-142213
Product Description
RCJT25 25mm INA 2 Bolt Flanged Bearing
Normal duty two bolt oval flanged cast iron housing unit complete with grub screw insert with R seals. The cast iron housing includes a grease nipple for re-lubrication.
The inserts can be removed allowing you to replace with a new insert once required which can be ordered separately.
Sizes (see diagram below):
d 25 mm
H 124 mm
U 46 mm
A 26,5 mm
A1 11 mm
A2 19 mm
B1 44,5 mm
d3 max 37,5 mm
J 99 mm
L 70 mm
N 11,5 mm
Q M6
V 70 mm
m 0,62 kg Mass
Cr 14900 N Basic dynamic load rating, radial
C0r 7800 N Basic static load rating, radial
CJT05 Designation of housing
GE25-XL-KRR-B Designation of bearing
KASK05 Bearing end cap, closed design. To be ordered separately.
Slot for bearing end cap
