Bearings
Ball Bearings
Dunlop & Budget Ball Bearings
Quick Code: BB-517654
SMR126-2RS ZEN Stainless Sealed Deep Groove Ball Bearing 6mm x 12mm x 4mm
Help Articles
Also Try
A Belts (13mm x 8mm)
Dunlop Taper Roller Bearings
Metric Oil Seals
Miniature Bearings
FAG Ball Bearings
Buy Now
Qty:
Product Specification
Ball rows
Single row bearing
Bore
Cylindrical bore
Brand
ZEN
Cage
Sheet steel cage
Clearance
Normal radial clearance
Current insulation
No current insulation
Inside Dia
6mm
Material
Stainless steel
Material of rolling elements
Stainless steel
Outer ring
Without flange/groove
Outside Dia
12mm
Sealing
Sealed
Temperature range
-20 to +120 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
4mm
Reference
SMR126-2RS
Additional Reference:
10128328
Quick Order Code
BB-517654
Product Description
The SMR126-2RS ZEN Stainless Sealed Deep Groove Ball Bearing is a high-precision, compact bearing designed for demanding applications requiring durability and reliable performance in small-scale mechanical systems.
Key Technical Specifications:
- Dimensions:
- Inside Diameter: 6mm
- Outside Diameter: 12mm
- Width: 4mm
- Construction Details:
- Brand: ZEN
- Bearing Type: Single Row Deep Groove Ball Bearing
- Material: Stainless Steel
- Bore Type: Cylindrical
- Cage Material: Sheet Steel
- Sealing: Sealed (2RS)
- Performance Characteristics:
- Temperature Range: -20°C to +120°C
- Tolerance Class: P0/PN2 / ABEC 1
- Radial Clearance: Normal
- Current Insulation: No
Typical Applications:
This versatile stainless steel bearing is ideal for precision applications in various industries, including:
- Miniature robotics
- Medical devices
- Precision instrumentation
- Small electrical motors
- Dental and surgical equipment
- Aerospace and defense mechanisms
The sealed design provides excellent protection against dust, moisture, and contaminants, ensuring long-lasting performance and minimal maintenance. Its stainless steel construction offers superior corrosion resistance, making it suitable for challenging environmental conditions.
