Bearings
Ball Bearings
Dunlop & Budget Ball Bearings
Quick Code: BB-517548
S683-2Z ZEN Stainless Shielded Deep Groove Ball Bearing 3mm x 7mm x 3mm
Help Articles
Also Try
A Belts (13mm x 8mm)
Metric Sizes - Dunlop & Budget
Metric Oil Seals
Miniature Bearings
FAG Ball Bearings
Buy Now
Qty:
Product Specification
Ball rows
Single row bearing
Bore
Cylindrical bore
Brand
ZEN
Cage
Sheet steel cage
Clearance
Normal radial clearance
Current insulation
No current insulation
Inside Dia
3mm
Material
Stainless steel
Material of rolling elements
Stainless steel
Outer ring
Without flange/groove
Outside Dia
7mm
Sealing
Shielded
Temperature range
-30 to +150 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
3mm
Reference
S683-2Z
Additional Reference:
10128120
Quick Order Code
BB-517548
Product Description
The S683-2Z ZEN Stainless Shielded Deep Groove Ball Bearing is a precision-engineered, compact miniature bearing designed for high-performance applications requiring exceptional durability and corrosion resistance. Constructed entirely from stainless steel, this miniature bearing offers reliable performance in small, precision mechanical systems.
Key Features:
- Ultra-compact dimensions: 3mm inside diameter × 7mm outside diameter × 3mm width
- Single row deep groove ball bearing design
- Shielded configuration with protective covers on both sides
- Stainless steel construction for superior corrosion resistance
- Sheet steel cage for enhanced structural integrity
- Cylindrical bore design
- Normal radial clearance
Technical Specifications:
- Inside Diameter: 3mm
- Outside Diameter: 7mm
- Width: 3mm
- Material: Stainless steel (rolling elements and rings)
- Sealing Type: Shielded (2Z)
- Temperature Range: -30°C to +150°C
- Tolerance Class: P0/PN2 / ABEC 1
- Current Insulation: None
- Outer Ring: Without flange/groove
Typical Applications:
- Miniature medical devices
- Precision scientific instruments
- Small robotics components
- Micro-mechanical systems
- Dental equipment
- Compact electronic mechanisms
- Marine and saltwater-resistant equipment
The S683-2Z ZEN bearing provides exceptional performance in environments requiring compact, corrosion-resistant, and precisely engineered bearing solutions. Its stainless steel construction and shielded design ensure reliable operation and extended service life in challenging application environments.
