Quick Code: BB-509463
BTW65 CTN9/SP SKF Axial Angular Contact Ball Bearing 65mm x 100mm x 44mm
Also Try
Angular Contact Bearings
Stainless Steel Angular Contact Bearings
Four Point Contact Bearings
UKF Angular Contact Bearings
Buy Now
Product Specification
Brand
SKF
Cage
Polyamide cage
Contact angle
60 degree
Fixing
Without fixing holes
Inside Dia
65mm
Lubrication hole
Without lubrication groove
Material
Standard bearing steel
Operating direction
Double direction bearing
Outside Dia
100mm
Product range
Single bearing
Sealing Type
Open
Temperature range
-20 to +120 °C
Tolerance class
Tolerance class SP
Width
44mm
Reference
BTW65
Additional Reference:
10102331
Quick Order Code
BB-509463
Product Description
BTW65 CTN9/SP SKF Axial Angular Contact Ball Bearing
This precision axial angular contact bearing from SKF is engineered for highly dynamic applications requiring exceptional load capacity, rigidity, and reliable performance. With its 60 degree contact angle design, the bearing efficiently handles both radial and high axial forces, making it ideal for demanding industrial and precision machinery applications.
Key Performance Features:
- 60 degree contact angle design for simultaneous support of radial and high axial forces
- Double-direction capability for bi-directional load support
- High accuracy and rigidity for precision applications
- Low-friction operation for efficient power transmission
- Polyamide cage for reliable bearing operation and reduced maintenance
- Open design providing excellent accessibility and lubrication control
- Wide operating temperature range from -20 degreeC to +120 degreeC
Specifications:
- Brand: SKF
- Bore Diameter: 65mm
- Outer Diameter: 100mm
- Width: 44mm
- Contact Angle: 60 degree
- Cage Material: Polyamide
- Sealing Type: Open
- Tolerance Class: SP
- Operating Direction: Double direction bearing
- Material: Standard bearing steel
- Lubrication: Without lubrication groove
- Fixing: Without fixing holes
- Temperature Range: -20 degreeC to +120 degreeC
Applications:
This bearing is particularly well-suited for precision machinery, screw drives, industrial automation, and similar applications where reliable axial and radial load management under highly dynamic conditions is critical to performance and system longevity.
