Quick Code: BB-494162
234420-M-SP FAG Axial Angular Contact Ball Bearing 100mm x 150mm x 60mm
Also Try
Angular Contact Bearings
Stainless Steel Angular Contact Bearings
Four Point Contact Bearings
UKF Angular Contact Bearings
Buy Now
Product Specification
Brand
FAG
Cage
Brass cage
Contact angle
60 degree
Fixing
With fixing holes
Inside Dia
100mm
Material
Standard bearing steel
Operating direction
Double direction bearing
Outside Dia
150mm
Product range
Single bearing
Sealing Type
Open
Temperature range
-30 to +150 °C
Tolerance class
Tolerance class SP
Width
60mm
Reference
234420-M-SP
Additional Reference:
10010620
Quick Order Code
BB-494162
Product Description
234420-M-SP FAG Axial Angular Contact Ball Bearing
This precision axial angular contact ball bearing is engineered for highly dynamic operating conditions, delivering exceptional performance in demanding industrial applications. With a 60 degree contact angle, this bearing excels at supporting both radial and high axial forces simultaneously, making it ideal for applications requiring outstanding accuracy, load capacity, and rigidity.
Key Performance Characteristics:
- High accuracy and precision alignment
- High load carrying capacity for radial and axial forces
- High rigidity and structural integrity
- Low friction operation for improved efficiency
- Double direction load capability
Design Features:
- 60 degree contact angle for optimal force distribution
- Brass cage construction for reliability and durability
- Fixed design with mounting holes for secure installation
- Open sealing design for applications where sealed bearings are not required
- Standard bearing steel material for proven performance
- Tolerance class SP for precision applications
- Compact yet robust dimensions: 100mm bore × 150mm OD × 60mm width
Specifications:
- Brand: FAG
- Bore Diameter: 100mm
- Outside Diameter: 150mm
- Width: 60mm
- Contact Angle: 60 degree
- Cage Material: Brass
- Sealing Type: Open
- Operating Temperature Range: -30 degreeC to +150 degreeC
- Tolerance Class: SP
- Mounting: With fixing holes
Applications:
The 234420-M-SP is particularly suited for precision screw drive systems, lead screw assemblies, machine tool spindles, and other high-speed, high-precision environments where reliable axial and radial load support is critical.
