234409-M-SP FAG Axial Angular Contact Ball Bearing 45mm x 75mm x 38mm
The 234409-M-SP FAG Axial Angular Contact Ball Bearing is a precision-engineered bearing designed for demanding industrial applications requiring high accuracy, exceptional load capacity, and reliable performance.
Design & Capabilities
This axial angular contact bearing is engineered for highly dynamic operating conditions in applications that demand:
- High accuracy and precision
- Exceptional load-carrying capacity
- High rigidity and minimal deflection
- Low friction operation
- Robust performance in challenging environments
Performance Features
The 60 degree contact angle enables this bearing to support both substantial radial forces and high axial forces simultaneously, making it ideal for complex loading scenarios. The double direction capability provides bidirectional load support, allowing the bearing to function effectively under loads applied in either direction. The brass cage design ensures reliable operation while minimizing wear, and the open sealing type offers maximum accessibility for applications where open designs are preferred.
Key Specifications
- Bore Diameter: 45mm
- Outer Diameter: 75mm
- Width: 38mm
- Contact Angle: 60 degree
- Cage Material: Brass
- Sealing Type: Open
- Operating Direction: Double direction (bidirectional)
- Fixing: With fixing holes for secure installation
- Tolerance Class: SP (high precision)
- Material: Standard bearing steel
- Temperature Range: -30 degreeC to +150 degreeC
- Product Type: Single bearing
Applications
This bearing is well-suited for precision machinery, screw drives, spindle assemblies, industrial gearboxes, and other high-performance equipment where reliability, accuracy, and the ability to handle combined radial and axial loads are critical to operation.
