7410-B-MP-UO FAG Single Row Angular Contact Ball Bearing 50mm x 130mm x 31mm
7410-B-MP-UO FAG Single Row Angular Contact Ball Bearing
This premium single row angular contact ball bearing from FAG is engineered to handle combined radial and axial loads simultaneously in high-speed, precision applications. The robust brass cage construction and optimized internal design deliver exceptional performance and reliability, making it ideal for demanding industrial environments including gearboxes, machine tool spindles, pumps, compressors, automotive transmissions, and other heavy-duty equipment where consistent performance is essential.
Key Specifications:
- Bore Diameter: 50mm
- Outer Diameter: 130mm
- Width: 31mm
- Row Type: Single Row
- Contact Angle: 40°
- Seal Type: Open Bearing (None)
- Cage Material: Brass
- Clearance: Normal Radial Clearance
- Tolerance Class: P0/PN2 (ABEC 1)
- Manufacturer: FAG
- Reference Number: 7410-B-MP-UO
Technical Features:
- 40° contact angle for optimal load distribution and handling of combined radial and axial forces
- Single row design accommodates axial loads in one direction
- Universal mounting bearing – two bearings can be arranged in O- or X-arrangement with clearance-free operation for versatile installation configurations
- Brass cage ensures excellent strength, durability, and thermal stability in demanding applications
- Standard bearing steel construction provides reliable performance across a wide temperature range
- Open bearing design allows for easy maintenance and cleaning
- Normal radial clearance provides optimal performance for standard industrial applications
- Operating Temperature Range: -20°C to +150°C
Applications:
This versatile bearing is ideal for a wide variety of industrial and precision applications including electric motors, gearboxes, pumps, compressors, machine tools, spindle assemblies, and automotive components. The 50mm bore and 130mm outer diameter make it particularly suitable for medium to large-scale applications requiring reliable performance under combined radial and axial loading at high speeds. Commonly used in automotive, industrial machinery, and precision equipment where durability and consistent performance are critical.
Why Choose FAG?
FAG is a leading global manufacturer renowned for exceptional quality standards and precision engineering. FAG angular contact bearings deliver superior reliability and extended service life, making them the preferred choice for critical applications requiring maximum uptime and consistent performance.
Reference: 7410-B-MP-UO-FAG
