7410-B-MP-UA FAG Single Row Angular Contact Ball Bearing 50mm x 130mm x 31mm
Help Articles
Also Try
Tab Washers
Lock Nuts
Metric Oil Seals
Dunlop & Budget Ball Bearings
SKF Ball Bearings
Buy Now
Product Specification
Arrangement
Bearing pair with a low axial clearance in O- and X-arrangem
Brand
FAG
Cage
Brass cage
Clearance
Normal radial clearance
Contact angle
40 degree
Inside Dia
50mm
Material
Standard bearing steel
Outer ring
Without flange/groove
Outside Dia
130mm
Row Type
Single
Seal
None, open bearing
Temperature range
-20 to +150 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
31mm
Reference
7410-B-MP-UA
Additional Reference:
10045748
Quick Order Code
BB-497837
Product Description
7410-B-MP-UA FAG Single Row Angular Contact Ball Bearing
This premium FAG angular contact ball bearing is engineered to handle simultaneous radial and axial loads with precision and reliability. As a single row design, it features a 40° contact angle optimized for high-speed applications and is ideal for demanding industrial environments requiring consistent performance.
Key Features:
- 40° contact angle for optimal load distribution and performance
- Single row design accommodating axial loads in one direction
- Brass cage construction for smooth, reliable operation
- Normal radial clearance for standard applications
- Open bearing design (unsealed) for maintenance-free operation in clean environments
- FAG manufacturing quality from a world-leading bearing manufacturer
- Dimensions: 50mm bore × 130mm outer diameter × 31mm width
Applications:
This bearing is ideal for high-speed, precision applications including:
- Gearboxes and transmission systems
- Industrial equipment and machinery
- Machine tool spindles
- Automotive and aerospace components
- Pump and motor assemblies
- Paired bearing arrangements (O and X-arrangement configurations available)
Specifications:
- Brand: FAG
- Model: 7410-B-MP-UA
- Bore Diameter: 50mm
- Outer Diameter: 130mm
- Width: 31mm
- Type: Single Row Angular Contact Ball Bearing
- Contact Angle: 40°
- Cage Material: Brass
- Clearance: Normal radial clearance
- Seal: Open bearing (none)
- Outer Ring: Without flange/groove
- Material: Standard bearing steel
- Tolerance Class: P0/PN2 (ABEC 1)
- Operating Temperature Range: -20°C to +150°C
- Arrangement: Bearing pair with low axial clearance in O- and X-arrangement
FAG angular contact bearings are renowned for their exceptional quality standards and durability, making them the preferred choice for demanding industrial applications worldwide.
