7410-BCBM SKF Single Row Angular Contact Ball Bearing
Help Articles
Also Try
Tab Washers
Lock Nuts
Metric Oil Seals
Dunlop & Budget Ball Bearings
SKF Ball Bearings
Female with Swivel Nut - 60 Coned Seat
Fluro Rod Ends - Series G - Male
Buy Now
Product Specification
Arrangement
Bearing pair with a low axial clearance in O- and X-arrangem
Brand
SKF
Cage
Brass cage
Clearance
Normal radial clearance
Contact angle
40 degree
Inside Dia
50mm
Material
Standard bearing steel
Outer ring
Without flange/groove
Outside Dia
130mm
Row Type
Single
Seal
None, open bearing
Temperature range
-20 to +150 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
31mm
Reference
7410-BCBM
Additional Reference:
10083959
Quick Order Code
BB-505847
Product Description
7410-BCBM SKF Single Row Angular Contact Ball Bearing
This premium single row angular contact ball bearing from SKF is engineered to handle combined radial and axial loads, making it an excellent choice for high-speed precision applications requiring dependable performance. The brass cage construction and open design provide excellent reliability and versatility for various industrial and mechanical applications.
Product Specifications
- Bore Diameter: 50mm
- Outer Diameter: 130mm
- Width: 31mm
- Row Configuration: Single Row
- Contact Angle: 40°
- Manufacturer: SKF
- Reference Number: 7410-BCBM
Design & Features
- Single row angular contact design optimised for efficient distribution of combined radial and axial loads
- Brass cage provides superior ball centring, stability, and excellent performance across temperature variations
- Open bearing design without seals for straightforward maintenance and accessibility
- Normal radial clearance suitable for standard applications
- Bearing pair configuration with low axial clearance in O- and X-arrangement for versatile mounting options
- Non-separable design ensuring structural integrity
- Tolerance class P0/PN2 (ABEC 1) for reliable precision performance
- Outer ring without flange or groove for flexible installation
Material & Operating Conditions
- Material: Standard bearing steel with brass cage
- Operating Temperature Range: -20°C to +150°C
- Arrangement: Bearing pair with low axial clearance in O- and X-arrangement
Typical Applications
Ideal for use in:
- Electric motors and rotating machinery
- Precision industrial equipment
- Gearboxes and transmission systems
- Compressors and pumps
- Machine tools requiring combined load support
- Agricultural and automotive equipment
- High-speed applications with moderate to heavy loads
SKF Quality Assurance: As the world's leading bearing manufacturer, SKF delivers exceptional quality standards and reliability, ensuring this angular contact bearing performs consistently in demanding industrial environments.
