7409-BCBM SKF Single Row Angular Contact Ball Bearing
Help Articles
Also Try
Tab Washers
Lock Nuts
Metric Oil Seals
Dunlop & Budget Ball Bearings
SKF Ball Bearings
Buy Now
Product Specification
Arrangement
Bearing pair with a low axial clearance in O- and X-arrangem
Brand
SKF
Cage
Brass cage
Clearance
Normal radial clearance
Contact angle
40 degree
Inside Dia
45mm
Material
Standard bearing steel
Outer ring
Without flange/groove
Outside Dia
120mm
Row Type
Single
Seal
None, open bearing
Temperature range
-20 to +150 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
29mm
Reference
7409-BCBM
Additional Reference:
10083957
Quick Order Code
BB-505846
Product Description
7409-BCBM SKF Single Row Angular Contact Ball Bearing
This premium single row angular contact ball bearing from SKF is engineered to handle combined radial and axial loads simultaneously, making it ideal for high-speed, precision applications. With its robust construction and reliable performance, this bearing is specifically designed as a bearing pair with low axial clearance, suitable for demanding industrial environments requiring precise load management.
Key Specifications:
- Bore Diameter: 45mm
- Outside Diameter: 120mm
- Width: 29mm
- Type: Single Row Angular Contact
- Brand: SKF
- Contact Angle: 40 degrees
- Seal Type: Open Design
Design Features:
- Bearing pair with low axial clearance for O- and X-arrangement configurations
- Brass cage construction for enhanced durability and performance
- Normal radial clearance for standard industrial applications
- Standard bearing steel material for reliable strength and longevity
- Outer ring without flange or groove for flexible mounting options
- Tolerance class P0/PN2 (ABEC 1) for precision performance
- Operating temperature range: -20°C to +150°C
- Open seal design allows for flexible lubrication options
Common Applications:
This angular contact bearing is ideal for:
- Gearboxes and transmission systems
- Spindle assemblies
- Industrial pump and motor shafts
- Precision machinery requiring high-speed operation
- Machine tool spindles
- Industrial compressors and blowers
- Equipment with combined load requirements
Backed by SKF's reputation for quality and precision engineering, this bearing delivers consistent performance and durability for critical industrial applications.
